Description
SPECIFICATIONS
After-sales Service Provided: Overseas third-party support available
Applicable Industries: Farms,Farms, Home Use, Retail
Brand Name: NoEnName_Null,Huaxia Brand
By wheel: 4WD
Cabin: Warm Air or AC is available
Certificate: CE
Color: Red, Blue,Deep Green, Light Green or Depend on client’s requirement
Condition: New,New
Core Components: ENGINE,Engine
Drive Type: Gear Drive
Engine Brand: other,YTO
Hign-concerned Chemical: None
Implement: Loader, Plough, Mower and More Implements
Key Selling Points: Multifunctional,Multifunctional
Machinery Test Report: Provided,Provided
Marketing Type: hot sale,Hot Product 2019
Option: Air Brakes, Hydraulic Valve Out, ROPS, Canopy
Place Of Origin: china
Place of Origin: Shandong, China
Rated Power: 50HP
Rated Power (HP): Other
Showroom Location: other,None
Tire: Radial Tire, Paddy Tire, Turf Tire
Type: Wheel Tractor,Wheel Tractor
Use: Farm Tractor
Video outgoing-inspection: Provided,Provided
Warranty: 1 years,1 Year
Warranty of Core Components: 1 Year
Warranty of core components: 1 Year
Weight: 2000 KG
Hello, my friend, I am Alice, because the shipping costs are constantly changing, and the shipping costs in different countries are also different, the prices in the link are reference prices, you can contact me first to get a more accurate price. Have a nice day!
50-60HP Tractor specification
4 Cylinder Engine
|
MODEL |
UNITS |
550 |
554 |
600 |
604 |
|
|
ENGINE |
|
4 cylinder JD Brand Diesel engine (JIANGDONG POWER) |
||||
|
Type |
|
In-line,water cooled,4-stroke,natural aspirated |
||||
|
Model |
|
JD4102 |
JD4102 |
JD4108 |
JD4108 |
|
|
Homolo gated power |
kw |
40.44 |
44.12 |
|||
|
Rated speed |
R/min |
2400 |
2400 |
2400 |
2400 |
|
|
No. of cylinders |
|
4 |
4 |
4 |
4 |
|
|
Max. Exhaust gas emperature |
°C |
≤600 |
≤600 |
≤600 |
≤600 |
|
|
Aspiration |
|
natural aspirated |
||||
|
Spark in sequence |
|
1-3-4-2 |
||||
|
Bore/Stroke |
mm |
102mm*105mm |
102mm*105mm |
|||
|
Displacement |
L |
3.432 |
3.432 |
3.432 |
3.432 |
|
|
Max torque operation |
N.m |
≥185 |
≥185 |
≥188 |
≥188 |
|
|
Fuel consumption |
g/kw.h |
≤245.0 |
≤245.0 |
≤245.0 |
≤245.0 |
|
|
Oil consumption |
g/kw.h |
≤2.04 |
≤2.04 |
≤2.04 |
≤2.04 |
|
|
oil pressure |
Kpa |
Normal working: 200-500. Idle speed working::≥80 |
||||
|
CLUTCH |
|
Single Disc, Dry, Dual-Stage, constant meshed |
||||
|
TRANSMISSION |
|
|
||||
|
Gear box |
|
2 axis 4X(2+1) gear group type |
||||
|
Shifting |
|
meshing sleeve gear shifting |
||||
|
Differential Gears |
|
Double planet wheels, closed type |
||||
|
Differential lock |
|
Pin type |
||||
|
Final transmission |
|
Planet wheel type |
||||
|
PTO SHAFT |
|
|
||||
|
Type |
|
Independent and synchronous P.T.O. |
||||
|
Speeds |
R/min |
540/760 or 540/1000 or 760/1000 |
||||
|
Spine shaft shape |
|
6 GEARS RECTANGLE SPLINE |
||||
|
HYDRAULICS |
|
|
||||
|
Three point linkage |
|
Category II |
||||
|
Control |
|
Position |
||||
|
Hydraulic output adaptor |
|
Size: M16X1.5, quantity: 1; output flow rate: 20L/min |
||||
Q: Why are zhuozhihao Tractors such awesome value for money?
A: zhuozhihao Tractors are awesome value because we are manufacturer. We have no commercial lease to pay. Tractors and implements are stored in a rural shed, so we pass the savings directly on to you.
Q: Do implements require any assembly?
A: Yes. Most implements have some assembly required, they’re typically partially assembled for transportation. Tightening of all bolts is required.
Q: What lubrication do implements require?
A: Unless otherwise stated, all implements with gearboxes, such as slashers, post hole borers and rotary tillers, are shipped dry and require the addition of gear oil.
Q: Is the three point linkage limited to just two positions? (Up or down).
A: No. The three point linkage can be stopped at any position.
Q: What type of three-point linkage does the tractor have?
A: The tractor has a Category 1 three-point linkage
Q: How much weight can the three point linkage lift?
A: This depends on which model tractor you purchase. Please review the specifications page.
Q: How much fuel does the tractor use?
A: Approximately 5 – 7 litres per hour, depending on engine capacity, speed, load, etc.
Please review the specifications page for more information.
Q: What speed and power does the PTO deliver?
A: The PTO has dual speeds: 540 / 1000 RPM.
Q: What type of brakes does the tractor have?
A: The Fumetsu has Non-Hydraulic Drum Brakes on the rear wheels.
